HVAC Chillers
Application Description:
Heating, ventilation and air conditioning (HVAC) chillers are refrigeration systems that provide cooling for industrial and commercial applications. They use water, oils or other fluids as refrigerants. HVAC chillers include a compressor, condenser, thermal expansion valve, evaporator, reservoir, and stabilization assembly. Compressing the refrigerant creates a high pressure, super heated gas that the condenser air-cools to a warm liquid. The thermal expansion valve (TXV) releases refrigerant into the evaporator, converting the warm liquid to a cool, dry gas. Often, a hot gas bypass is used to stabilize the cooling output by allowing the hot gas to warm up the evaporator. This causes a reduction in cooling efficiency, but stabilizes the chilled water temperatures. When water is pumped from the reservoir to the compressor, the chilling cycle begins again.
 Packaged Chillers Non-expandable (integrated pump tank) 1.5Ton – 20Ton Single / Dual Circuits Single / Dual Pumps |
 SAE Series Modular Chillers Expandable (pump & tank on separate skid) 1.5Ton – 200Ton Single / Dual Circuits |
 SAR Series Split Chillers Expandable (Outdoor Condensing Unit) (pump, tank, evaporator on indoor skid) 1.5Ton – 200Ton Single / Dual Circuits |
